3D Solid Carbide 3mm Drill Bit For Iron Cast Iron Inconel with
reduced shank
Introduction:
A high-performance 3D solid carbide drill bit (5mm diameter) designed for demanding applications in cast iron, iron, and Inconel alloys.
Specification:
| Flute dia (D) | Shank dia (d) | OAL(L) | Groov length (L2) | Max.depth of cutting (L1) | Shank length(LS) |
| 3 | 6 | 62 | 20 | 14 | 36 |
| 3.25 | 6 | 62 | 20 | 14 | 36 |
| 3.3 | 6 | 62 | 20 | 14 | 36 |
| 3.4 | 6 | 62 | 20 | 14 | 36 |
| 3.5 | 6 | 62 | 20 | 14 | 36 |
| 3.7 | 6 | 62 | 20 | 14 | 36 |
| 4 | 6 | 66 | 24 | 17 | 36 |
| 4.2 | 6 | 66 | 24 | 17 | 36 |
| 4.3 | 6 | 66 | 24 | 17 | 36 |
| 4.5 | 6 | 66 | 24 | 17 | 36 |
| 4.65 | 6 | 66 | 24 | 17 | 36 |
| 4.8 | 6 | 66 | 28 | 20 | 36 |
| 5 | 6 | 66 | 28 | 20 | 36 |
| 5.1 | 6 | 66 | 28 | 20 | 36 |
| 5.2 | 6 | 66 | 28 | 20 | 36 |
| 5.5 | 6 | 66 | 28 | 20 | 36 |
| 5.55 | 6 | 66 | 28 | 20 | 36 |
| 5.8 | 6 | 66 | 28 | 20 | 36 |
| 6 | 6 | 66 | 28 | 20 | 36 |
| 6.1 | 8 | 79 | 34 | 24 | 36 |
| 6.2 | 8 | 79 | 34 | 24 | 36 |
| 6.3 | 8 | 79 | 34 | 24 | 36 |
| 6.5 | 8 | 79 | 34 | 24 | 36 |
| 6.6 | 8 | 79 | 34 | 24 | 36 |
| 6.8 | 8 | 79 | 34 | 24 | 36 |
| 6.9 | 8 | 79 | 34 | 24 | 36 |
| 7 | 8 | 79 | 34 | 24 | 36 |
| 7.1 | 8 | 79 | 41 | 29 | 36 |
| 7.4 | 8 | 79 | 41 | 29 | 36 |
| 7.5 | 8 | 79 | 41 | 29 | 36 |
| 7.8 | 8 | 79 | 41 | 29 | 36 |
| 8 | 8 | 79 | 41 | 29 | 36 |
| 8.1 | 10 | 89 | 47 | 35 | 40 |
| 8.4 | 10 | 89 | 47 | 35 | 40 |
| 8.5 | 10 | 89 | 47 | 35 | 40 |
| 8.6 | 10 | 89 | 47 | 35 | 40 |
| 8.7 | 10 | 89 | 47 | 35 | 40 |
| 8.8 | 10 | 89 | 47 | 35 | 40 |
| 9 | 10 | 89 | 47 | 35 | 40 |
| 9.3 | 10 | 89 | 47 | 35 | 40 |
| 9.5 | 10 | 89 | 47 | 35 | 40 |
| 9.6 | 10 | 89 | 47 | 35 | 40 |
| 9.8 | 10 | 89 | 47 | 35 | 40 |
| 10 | 10 | 89 | 47 | 35 | 40 |
| 10.25 | 12 | 102 | 55 | 40 | 45 |
| 10.4 | 12 | 102 | 55 | 40 | 45 |
| 10.5 | 12 | 102 | 55 | 40 | 45 |
| 10.6 | 12 | 102 | 55 | 40 | 45 |
| 10.8 | 12 | 102 | 55 | 40 | 45 |
| 11 | 12 | 102 | 55 | 40 | 45 |
| 11.2 | 12 | 102 | 55 | 40 | 45 |
| 11.5 | 12 | 102 | 55 | 40 | 45 |
| 11.8 | 12 | 102 | 55 | 40 | 45 |
| 12 | 12 | 102 | 55 | 40 | 45 |
| 12.25 | 14 | 107 | 60 | 43 | 45 |
| 12.5 | 14 | 107 | 60 | 43 | 45 |
| 12.7 | 14 | 107 | 60 | 43 | 45 |
| 12.75 | 14 | 107 | 60 | 43 | 45 |
| 12.8 | 14 | 107 | 60 | 43 | 45 |
| 13 | 14 | 107 | 60 | 43 | 45 |
| 13.1 | 14 | 107 | 60 | 43 | 45 |
| 13.5 | 14 | 107 | 60 | 43 | 45 |
| 13.8 | 14 | 107 | 60 | 43 | 45 |
| 14 | 14 | 107 | 60 | 43 | 45 |
| 14.25 | 16 | 115 | 65 | 45 | 48 |
| 14.5 | 16 | 115 | 65 | 45 | 48 |
| 14.75 | 16 | 115 | 65 | 45 | 48 |
| 14.8 | 16 | 115 | 65 | 45 | 48 |
| 15 | 16 | 115 | 65 | 45 | 48 |
| 15.1 | 16 | 115 | 65 | 45 | 48 |
| 15.5 | 16 | 115 | 65 | 45 | 48 |
| 15.8 | 16 | 115 | 65 | 45 | 48 |
| 16 | 16 | 115 | 65 | 45 | 48 |
| 16.5 | 18 | 123 | 73 | 51 | 48 |
| 16.75 | 18 | 123 | 73 | 51 | 48 |
| 16.8 | 18 | 123 | 73 | 51 | 48 |
| 17 | 18 | 123 | 73 | 51 | 48 |
| 17.5 | 18 | 123 | 73 | 51 | 48 |
| 17.8 | 18 | 123 | 73 | 51 | 48 |
| 18 | 18 | 123 | 73 | 51 | 48 |
| 18.5 | 20 | 131 | 79 | 55 | 50 |
| 18.8 | 20 | 131 | 79 | 55 | 50 |
| 19 | 20 | 131 | 79 | 55 | 50 |
| 19.5 | 20 | 131 | 79 | 55 | 50 |
| 19.8 | 20 | 131 | 79 | 55 | 50 |
| 20 | 20 | 131 | 79 | 55 | 50 |
Features:
Material: Premium micro-grain carbide for extreme wear resistance
Geometry:
3D margin design for superior hole accuracy and surface finish
Optimized flute design for efficient chip evacuation
140° point angle for reduced cutting forces
Specialized Coating: TiAlN (or AlCrN) for heat resistance in high-temp alloys (Inconel)
Reduced Shank: Improves grip in chucks and minimizes vibration
Applications
Cast Iron/Iron: Automotive parts, machinery components
Inconel: Aerospace, turbine blades, high-temperature environments
Performance Benefits
Detailed Pictures:
Our workshop:
New Customer Special Offers:
To help you experience our premium products, we’re excited to offer
the following exclusive promotions for first-time buyers:
1.Free Test Samples
Get free samples (total value ≤ $20 USD) when you cover the international shipping cost.
Perfect for evaluating our product quality and performance
risk-free.
2.$50 USD Discount on First Order
New customers can enjoy a $50 discount on the first order of $500 or more.
A great way to start our partnership with extra value!
Our advantages:
1.Advanced grinding machines: All of our grinding machines are WALTER and SAACKE brands.
2.Advanced inspection machines: We have ZOLLER, OMEGA, PG1000, etc. For inspecting each carbide
tools.
3.Fast feedback: we offer 24 hours online service
4.Strict quality control system:
We strictly adhere to a three-stage inspection process for each
tool:
Raw material inspection
Semi-finished product inspection after production
Final inspection after coating (pre-shipment check)
