5D Through coolant carbide drill bits for CNC machines for
stainless steel 304 316L
Specification:
| Flute dia (D) | Shank dia (d) | OAL(L) | Groov length (L2) | Max.depth of cutting (L1) | Shank length(LS) |
| 3 | 6 | 62 | 20 | 14 | 36 |
| 3.25 | 6 | 62 | 20 | 14 | 36 |
| 3.3 | 6 | 62 | 20 | 14 | 36 |
| 3.4 | 6 | 62 | 20 | 14 | 36 |
| 3.5 | 6 | 62 | 20 | 14 | 36 |
| 3.7 | 6 | 62 | 20 | 14 | 36 |
| 4 | 6 | 66 | 24 | 17 | 36 |
| 4.2 | 6 | 66 | 24 | 17 | 36 |
| 4.3 | 6 | 66 | 24 | 17 | 36 |
| 4.5 | 6 | 66 | 24 | 17 | 36 |
| 4.65 | 6 | 66 | 24 | 17 | 36 |
| 4.8 | 6 | 66 | 28 | 20 | 36 |
| 5 | 6 | 66 | 28 | 20 | 36 |
| 5.1 | 6 | 66 | 28 | 20 | 36 |
| 5.2 | 6 | 66 | 28 | 20 | 36 |
| 5.5 | 6 | 66 | 28 | 20 | 36 |
| 5.55 | 6 | 66 | 28 | 20 | 36 |
| 5.8 | 6 | 66 | 28 | 20 | 36 |
| 6 | 6 | 66 | 28 | 20 | 36 |
| 6.1 | 8 | 79 | 34 | 24 | 36 |
| 6.2 | 8 | 79 | 34 | 24 | 36 |
| 6.3 | 8 | 79 | 34 | 24 | 36 |
| 6.5 | 8 | 79 | 34 | 24 | 36 |
| 6.6 | 8 | 79 | 34 | 24 | 36 |
| 6.8 | 8 | 79 | 34 | 24 | 36 |
| 6.9 | 8 | 79 | 34 | 24 | 36 |
| 7 | 8 | 79 | 34 | 24 | 36 |
| 7.1 | 8 | 79 | 41 | 29 | 36 |
| 7.4 | 8 | 79 | 41 | 29 | 36 |
| 7.5 | 8 | 79 | 41 | 29 | 36 |
| 7.8 | 8 | 79 | 41 | 29 | 36 |
| 8 | 8 | 79 | 41 | 29 | 36 |
| 8.1 | 10 | 89 | 47 | 35 | 40 |
| 8.4 | 10 | 89 | 47 | 35 | 40 |
| 8.5 | 10 | 89 | 47 | 35 | 40 |
| 8.6 | 10 | 89 | 47 | 35 | 40 |
| 8.7 | 10 | 89 | 47 | 35 | 40 |
| 8.8 | 10 | 89 | 47 | 35 | 40 |
| 9 | 10 | 89 | 47 | 35 | 40 |
| 9.3 | 10 | 89 | 47 | 35 | 40 |
| 9.5 | 10 | 89 | 47 | 35 | 40 |
| 9.6 | 10 | 89 | 47 | 35 | 40 |
| 9.8 | 10 | 89 | 47 | 35 | 40 |
| 10 | 10 | 89 | 47 | 35 | 40 |
| 10.25 | 12 | 102 | 55 | 40 | 45 |
| 10.4 | 12 | 102 | 55 | 40 | 45 |
| 10.5 | 12 | 102 | 55 | 40 | 45 |
| 10.6 | 12 | 102 | 55 | 40 | 45 |
| 10.8 | 12 | 102 | 55 | 40 | 45 |
| 11 | 12 | 102 | 55 | 40 | 45 |
| 11.2 | 12 | 102 | 55 | 40 | 45 |
| 11.5 | 12 | 102 | 55 | 40 | 45 |
| 11.8 | 12 | 102 | 55 | 40 | 45 |
| 12 | 12 | 102 | 55 | 40 | 45 |
| 12.25 | 14 | 107 | 60 | 43 | 45 |
| 12.5 | 14 | 107 | 60 | 43 | 45 |
| 12.7 | 14 | 107 | 60 | 43 | 45 |
| 12.75 | 14 | 107 | 60 | 43 | 45 |
| 12.8 | 14 | 107 | 60 | 43 | 45 |
| 13 | 14 | 107 | 60 | 43 | 45 |
| 13.1 | 14 | 107 | 60 | 43 | 45 |
| 13.5 | 14 | 107 | 60 | 43 | 45 |
| 13.8 | 14 | 107 | 60 | 43 | 45 |
| 14 | 14 | 107 | 60 | 43 | 45 |
| 14.25 | 16 | 115 | 65 | 45 | 48 |
| 14.5 | 16 | 115 | 65 | 45 | 48 |
| 14.75 | 16 | 115 | 65 | 45 | 48 |
| 14.8 | 16 | 115 | 65 | 45 | 48 |
| 15 | 16 | 115 | 65 | 45 | 48 |
| 15.1 | 16 | 115 | 65 | 45 | 48 |
| 15.5 | 16 | 115 | 65 | 45 | 48 |
| 15.8 | 16 | 115 | 65 | 45 | 48 |
| 16 | 16 | 115 | 65 | 45 | 48 |
| 16.5 | 18 | 123 | 73 | 51 | 48 |
| 16.75 | 18 | 123 | 73 | 51 | 48 |
| 16.8 | 18 | 123 | 73 | 51 | 48 |
| 17 | 18 | 123 | 73 | 51 | 48 |
| 17.5 | 18 | 123 | 73 | 51 | 48 |
| 17.8 | 18 | 123 | 73 | 51 | 48 |
| 18 | 18 | 123 | 73 | 51 | 48 |
| 18.5 | 20 | 131 | 79 | 55 | 50 |
| 18.8 | 20 | 131 | 79 | 55 | 50 |
| 19 | 20 | 131 | 79 | 55 | 50 |
| 19.5 | 20 | 131 | 79 | 55 | 50 |
| 19.8 | 20 | 131 | 79 | 55 | 50 |
| e | 20 | 131 | 79 | 55 | 50 |
| 5D Customized sizes through coolant carbide drill bits are also
available |
Introduction:
5D through-coolant carbide drill bits are high-performance cutting
tools designed for deep-hole drilling (5x diameter depth) in tough
materials like stainless steel 304 and 316L on CNC machines. These drills feature internal coolant channels for
efficient chip evacuation, heat dissipation, and extended tool
life.
Features:
1. Material: Made from micro-grain carbide for hardness and wear resistance.
2. Geometry: Optimized point angle (140°) and helix angle for stainless steel,
reducing work hardening.
3. Through-Coolant Design: High-pressure coolant flows directly to the cutting edge,
improving chip removal and reducing heat buildup.
4. 5D Length: Suitable for deep holes (5x drill diameter) without frequent
retraction.
5. Coating: Often TiAlN or AlCrN for heat resistance and lubricity in
stainless steel.
Detailed Pictures:
Promotion policy:
Free sample: Free samples can be provided, if client is willing to pay the
shipping cost.
Special offer for new customers: Enjoy USD50 discount when you spend USD500+ on your first order.
Our advantages:
1.Advanced grinding machines: All of our grinding machines are WALTER and SAACKE brands.
2.Advanced inspection machines: We have ZOLLER, OMEGA, PG1000, etc. For inspecting each carbide
tools.
3.Highly skilled design team: We are specialized in producing complicated customized carbide
tools and we can design the carbide tools according to the work
pieces.
Our workshop:
Our exhibition:
